FF-760AW Fiber Optic Conector Checking Fiber Microscope Fiber Endface Inspection USB and WIFI Connection Supported

Name: FF-760AW Fiber Optic Conector Checking Fiber Microscope Fiber Endface Inspection USB and WIFI Connection Supported
Brand: FirstFiber Technologies
Price: 970 USD
Availability: InStock

$970.00 USD

Shipping calculated at checkout.

Quantity

Inventory: 36 remaining available

FF-760AW Fiber Microscope

USB & WIFI supported

- Wifi / USB quick switch for dual use
- USB digital support in Windows/Linus/Mac
- Wifi support in Android and iOS
- Image capture feature to save time
- Built-in lithium rechargeable battery for 5hr
- 98% consistent alignment to centralize end face
- 400× magnification, <1µm resolution
- LED button for light source control
- CE/CEM/RoHS Certified
- External Interface: micro USB
- No need exterior Wireless AP or Module

Specification

Items	Value
Magnification	400X
Resolution	<1.0μm
Field of View	X: 0.3487mm Y: 0.2632mm
Laser Source	Blue LED
Focus Method	Unidirectional manual
Focus Time	1~5 seconds
Snapshot Button	yes
WiFi and USB Switch Button	yes
Communication Port	Micro USB
Connection Standard	WiFi 802.11 and USB2.0
Wireless Frequency	2.4GHz
Wireless Transmission Distance	20m
Smartphone Compatibility	Android 4.4 and above; IOS 8.0 and above
Voltage	5V
Battery	3100mHA Lithium battery
Charging Time	≤5h
Testing Time	≥5h
Dimension	1953cm
Weight	0.175kg
Working Temperature	-10 ^oC~50 ^oC
Storage Temperature	-20 ^oC~60 ^oC
Humidity	<90% (non-condensing)
Standard Accessories
Name		Quantity
Fiber Microscope		1pc
Adapter SC-PC-F (for SC/PC adaptor and connector)		1pc
Adapter FC-PC-F (for FC/PC adaptor and connector)		1pc
Adapter LC-PC-F (for LC/PC adaptor and connector)		1pc
USB cable		1pc
